Datakom DKG-309 - Unit Mounting Guidelines; Wiring Procedures and Safety

DKG-309 User Manual
(11.05.2009)
1.2 Mounting the Unit
The unit is designed for panel mounting. The user should not be able to access parts of the
unit other than the front panel.
Mount the unit on a flat, vertical surface. The unit fits into a standard panel meter opening of
151x111
millimeters. Before mounting, remove the
pass the unit through the mo
unting opening. The unit will be maintained in its position by the
brackets spring.
Engine body must be grounded for correct operation of
the unit, otherwise incorrect voltage and frequency
measurements may occur.
The output of the current transformers shall be 5 Amperes. The input current rating of the current
transformers may be selected as needed (between
shall be connected by separate cable pairs from each transformer, to related inputs. Never use common
terminals or grounding. The power rating of the transformer should be at least 5
use 1% precision transformers.
If analogue sender
s (e.g. temperature
possible to use auxiliary displays
, otherwise the unit may be d
fuel level displays are
already present on the generator control panel, do not connect the
unit
. The unit is factory programmed for VDO type
selectable via programming menu. Please check the programming section.
The
programmable digital inputs are compatible with both
closed’
contacts, switching either to
The charge alternator connection terminal provides also the excitation current, thus it is not
necessary to use an exter
nal charge lamp.
1.3 Wiring the Unit
WARNING: THE UNIT IS NOT FUSED.
Use external fuses for
Generator phase:
Install the fuses as nearly as possible to the unit in a
place easily accessible
The fuse rating should be 6 Amps.
WARNING: ELECTRICITY CAN KILL
ALWAYS disconnect the power BEFORE connecting the unit.
1)
ALWAYS remove the plug connectors when inserting wires with a screwdriver.
2)
An appropriate and readily accessible
automatic fuses) MUST be provided as part of the installation.
3)
The building mains supply MUST incorporate appropriate short
protection (e.g. a fuse or circuit breaker) of High Breaking Capacity (HBC, at
lea
st 1500A).
4)
Use cables of adequate current carrying capacity (at least 0.75mm
temperature range.
