Datalogic DX8200 Quick Reference Guide

DX8200 CONTROLLER
QUICK GUIDE
10
Reading Conditions:
•
ANSI Grade B minimum codes or better
The following tables describe the requirements for standard applications. Please contact Datalogic for specific
advice on maximizing the reading performance possibilities to obtain the best performance for your application.
Minimum Code Height for Omnidirectional Reading (mm)
Conveyor Speed (m/s) 0.5 1 1.5 2 2.5 3
0.25
10 12 14 17 19 21
0.30
12 14 16 18 20 22
0.33
13 14 17 19 21 23
0.38
14 16 18 20 22 24
0.50
18 19 21 23 25 27
0.60
21 22 24 26 28 30
2/5 Interleaved
Code Resolution (mm)
1.00
34 35 36 37 39 41
Table 1
Minimum Code Height for Omnidirectional Reading (mm)
Conveyor Speed (m/s) 0.5 1 1.5 2 2.5 3
0.25
9 10 12 15 17 19
0.30
10 11 13 16 18 20
0.33
11 12 14 16 18 20
0.38
12 13 15 17 19 21
0.50
15 16 17 19 21 24
0.60
18 19 20 21 23 26
Code 39
Code Resolution (mm)
1.00
28 29 30 31 32 34
Table 2
Minimum Code Height for Omnidirectional Reading (mm)
Conveyor Speed (m/s) 0.5 1 1.5 2 2.5 3
0.25
7 9 12 14 16 18
0.30
8 10 12 15 17 19
0.33
9 11 13 15 17 19
0.38
10 12 14 16 18 20
0.50
12 13 16 18 20 22
0.60
14 15 17 19 21 24
Code 128 – Ean 128
Code Resolution (mm)
1.00
22 23 24 26 28 30
Table 3
Minimum Code Height for Omnidirectional Reading (mm)
Conveyor Speed (m/s) 0.5 1 1.5 2 2.5 3
0.25
12 14 16 18 20 22
0.30
13 15 17 20 22 24
0.33
14 16 18 20 23 25
0.38
16 18 20 22 24 26
0.50
20 22 24 26 28 30
0.60
23 25 27 29 31 34
Codabar
Code Resolution (mm)
1.00
36 38 40 42 44 47
Table 4
