Datalogic Magellan 2200VSΩ User Manual

Site Preparation and Installation
22 Magellan
®
2200VS/2200VS and 2300HS/2300HS
Figure 2-4. Magellan
®
2300HS Cable Routing Options
9. Verify operation by scanning a few known-good bar code labels. The
scanner should now be communicating the bar code data to the
POS terminal.
This completes the installation instructions for this model.
Connector Cover
NOTE
Reference Chapter 4, Problem Isolation if the scanner
does not perform as expected.

Datalogic Magellan 2200VSΩ Specifications

General

Brand	Datalogic
Model	Magellan 2200VSΩ
Category	Barcode Reader
Language	English
