Datalogic Matrix N Series User Manual

MATRIX N FAMILY HOST MODE PROGRAMMING
24
4
PARAMETER
TYPE
STRING
DATA
0
EXPOSURE_TIMEx
M120-3xx-xxx
(continued)
Disabled
1 to 15000
Very High-Power Strobed
1 to 1000
NOTE: The Exposure Time parameter is measured in s and range of valid
values depends on the Matrix model and the Internal Lighting setting.
Gain
0
GAINx
Range: 4 to 32
(For M120-2xx models)
Range: 8 to 32
(For M120-3xx models)
Range: 1 to 40
(For M210N all models)
Range: 4 to 48
(For M300N all models)
Range: 4 to 48
(For M410N-500-010 models)
Range: 6 to 48
(For M410N-700-010 models)
Range: 1 to 25
(For M450N all models)
Gain Multiplier
1
GAINMULTIPLIERx
0 = X1
1 = X2
2 = X3
3 = X4
4 = X5
5 = X6
6 = X7
7 = X8
8 = X9
9 = X10
Reading Distance (mm)
0
READING_DISTANCEx
Range: 40 to 120 mm
(For M210N-2x5-x1x models)
Range: 22 to 452 mm
(For M300N-4x2-0xx models)
4.2 CODE SETUP
4.2.1 2D Codes
PARAMETER
TYPE
STRING
DATA
DATA MATRIX ECC 200
Identical Codes
2
2D_ID_CODESx
false = Disabled
true = Enabled
Image Mirroring
2
2D_IMAGE_MIRRORINGx
false = Disabled
true = Enabled
Grey Level Calibration
2
2D_GREY_LEVEL_CALIBRATIONx
false = Disabled
true = Enabled
