Datalogic Matrix N Series User Manual

MATRIX N FAMILY HOST MODE PROGRAMMING
38
4
4.2.4 Outputs
PARAMETER
TYPE
STRING
DATA
OUTPUTS
Active State
1
LOCOUT_ACTIVE_STATE_x
0 = Active Closed
1 = Active Open
Line Function
1
LOCOUT_MODE_x
0 = General Purpose
2 = External Ill – Always On
3 = External Ill – Strobed
Number of Events
0
LOCOUT_NUM_OF_EVENTS_x
Range 1 to 255
Line Type
1
LOCOUT_LINE_TYPE_x
0 = NPN
1 = PNP
2 = Push-Pull
4.2.5 LEDs
PARAMETER
TYPE
STRING
DATA
GREEN SPOT
Active State
1
OUT_ACTIVE_STATE_1
0 = Active Closed
1 = Active Open
Number of Events
0
OUT_NUM_OF_EVENTS_1
Range 1 to 255
RED SPOT
Active State
1
OUT_ACTIVE_STATE_2
0 = Active Closed
1 = Active Open
Number of Events
0
OUT_NUM_OF_EVENTS_2
Range 1 to 255
