Datalogic Matrix N Series - Examples

PROGRAMMING STRINGS
21
3
3.3 EXAMPLES
- 1-
Set Image Setting 2 Exposure Time parameter to 400  s:
Type:
0
Range:
6 to 500
Data:
400
The programming string is:
SET<space>EXPOSURE_TIME1<space>400 <CR><LF>
- 2 -
Set GainMultiplier parameter to X3:
Type:
1
List:
X1, X2, X3, X4, X5, X6, X7, X8, X9, X10
Data:
2
The programming string is:
SET<space>GAINMULTIPLIER<space>2 <CR><LF>
- 3 -
Set Data Matrix ECC 200 Image Mirroring parameter to enabled:
Type:
2
Item List:
true (Enabled), false (Disabled)
Data:
true
The programming string is:
SET<space>2D_IMAGE_MIRRORING<space>true <CR><LF>
- 4 -
Set Data Matrix ECC 200 Image Filter Placeholder character to ‘&’:
Type:
3
Item List:
any printable character
Data:
&
The programming string is:
SET<space>2D_PLACEHOLDER<space>& <CR><LF>
