Page #30 background imageLoading...
Page #30 background image
MATRIX N FAMILY HOST MODE PROGRAMMING
26
PARAMETER
TYPE
STRING
DATA
AZTEC
Identical Codes
2
2D_ID_CODESx
false = Disabled
true = Enabled
Image Mirroring
2
2D_IMAGE_MIRRORINGx
false = Disabled
true = Enabled
Grey Level Calibration
2
2D_GREY_LEVEL_CALIBRATIONx
false = Disabled
true = Enabled
Code Color
1
2D_CODE_COLORx
0 = Black
1 = White
2 = Both Colors
Code Contrast
1
2D_CODE_CONTRASTx
0 = High
1 = Standard
2 = Low
3 = Very Low
4 = Automatic
PARAMETER
TYPE
STRING
DATA
MAXICODE
Identical Codes
2
2D_ID_CODESx
false = Disabled
true = Enabled
Image Mirroring
2
2D_IMAGE_MIRRORINGx
false = Disabled
true = Enabled
Grey Level Calibration
2
2D_GREY_LEVEL_CALIBRATIONx
false = Disabled
true = Enabled
Code Color
1
2D_CODE_COLORx
0 = Black
1 = White
2 = Both Colors
Code Contrast
1
2D_CODE_CONTRASTx
0 = High
1 = Standard
2 = Low
3 = Very Low
4 = Automatic
Partial Code Tx
2
2D_PARTIAL_CODE_TXx
false = Disabled
true = Enabled
PARAMETER
TYPE
STRING
DATA
DOTCODE
Identical Codes
2
2D_ID_CODESx
false = Disabled
true = Enabled
Image Mirroring
2
2D_IMAGE_MIRRORINGx
false = Disabled
true = Enabled
Grey Level Calibration
2
2D_GREY_LEVEL_CALIBRATIONx
false = Disabled
true = Enabled
Code Color
1
2D_CODE_COLORx
0 = Black
1 = White
2 = Both Colors
Code Contrast
1
2D_CODE_CONTRASTx
0 = High
1 = Standard
2 = Low
3 = Very Low
4 = Automatic
Enable High
Resolution
2
2D_HIGH_RESOLUTIONx
false = Disabled
true = Enabled
