Datalogic PowerScan CM9630

System Connections
14 BC96XX BASE STATIONS
Pull out the multi-interface cable and put the lever back into lock position.
Connecting BC9631 multi-interface cable
Unscrew the no-tool screw to open the front door, connect the multi-inter-
face cable, close the door and screw it back.
To disconnect the multi-interface cable, open the front door, pull out the
cable and screw the front door back.
Lock position
Unscrew
Insert
Screw
