Technical Specifications
32
QUICKSCAN™ QBT/QM2500
ENVIRONMENTAL CHARACTERISTICS
Operating Tempera-
ture
0 °C to + 50 °C (+32° F to +122 °F)
Storage Temperature -40 °C to + 70 °C (-40 ° F to +158 °F)
Humidity 0 - 95% non condensing
Drop Resistance
IEC 60068-2-31 Tested
1,5 m (4,9 ft)
ESD Protection 16 KV
Protection Class IP52
Cable Length Refer to www.datalogic.com
OPTICAL CHARACTERISTICS
Optical Format 1/4"
Active Imager Size 3896 um (H) x 2453 um (V)
Active Pixels 1280 H x 800 V
Illumination System
LED source
Red Emission (wavelength - 617 nm)
Aiming System
LED source
Blue Emission (wavelength - 468nm)
Ambient Light Up to 110,000 lux
Tilt Tolerance 0° - 360°
Pitch Tolerance ± 65°
Skew Tolerance ± 65°
Field of View 35° x 22°
PCS
(Datalogic Test Chart)
minimum 15%
DOF - DEPTH OF FIELD (TYPICAL)
A
a. All labels grade A, typical environmental light, 20°C, label inclination 10°
Symbology DOF Range
Code 39
5 mil: 0.5 - 25.0 cm (0.19" - 9.8")
10 mil: 0.5 - 38 cm (0.19" - 14.9")
EAN13
13 mil: 0.5 - 51.0 cm (0.19" - 20.1")
PDF417
6.7 mil: 0.5 - 21.0 cm (0.19" - 8.3")
Datamatrix
10 mil: 0.5- 21.5 cm (0.19" - 8.5")
Code 128
5 mil: 2 - 21.5 cm (0.8" - 8.5")
QR Code
20 mil: 0- 37 cm (0" - 14.6")
Max Resolution
1D Min = 3 mil
PDF417 Min = 3 mil
Datamatrix Min = 5 mil
