Datamax A-Class A-4212

22 A-Class
Media
Peel Assembly
Release Lever
Peel Assembly
4. Remove the labels from 12 inches (30 cm) of the Media Liner. Route the Media Liner
down to the Peel Assembly, over the Latch Roller, and through the Slot as shown below.
Media
Peel Assembly
Media Liner
