26 A-Class

3.3 Loading Ribbon

Load ribbon (for thermal transfer media) according to its coated side and the printer model.

;

Using a ribbon slightly wider than the media (and liner) is recommended for added protection against abrasive wear.

3.3.1 Right Hand Models

Load ribbon as follows:

1. Orient the unwind position of the Ribbon according to the coated side (CSI or CSO) and then slide the Ribbon Roll

completely onto the Ribbon Supply Hub, as shown below:

CSO Ribbon

Roll

Ribbon

Supply Hub

Ribbon

Supply Hub

CSI Ribbon

Roll

CSO Ribbon CSI Ribbon
