Datamax A-Class A-4212 User Manual

24 A-Class
6. Position the Media Guide lightly against the side of the media.
Locking Post
Head Lift Lever
Media Guide
7. Adjust the Media Sensor over the labels (see Section 3.2).
8. If printing on thermal transfer media, load ribbon (see Section 3.3); otherwise go to
Step 9.
9. Lower the Head Lift Lever until it is completely and securely engaged onto the Locking
Post.
10. If loading media for the first time or if changing to a different media type or size, press
and hold the FEED Key until at least two labels have been output (see Section 3.4).
11. Adjust the Leveling Cam (see Section 5.3.1).

Datamax A-Class A-4212 Specifications

General

Brand	Datamax
Model	A-Class A-4212
Category	Label Maker
Language	English
