Datapath X4 User Guide

Specication
x4 Physical Dimensions 235 x 175 x 44mm/9.25” x 6.9” x 1.75”
Operating Temperature Range 0 - 35 DegC/32 - 96 DegF
Power Requirements 5V DC, 11W. Universal mains power adapter
supplied (100-240V)
Cooling
The unit contains a cooling fan. The input
and output vents should not be restricted
USB 2.0
Full speed (12Mbits/s) operation supported
1 x Dual link DVI capture
To 330 Mpixels/s
Input Surface 4k x 4k maximum
4 x Single link DVI or analog RGB outputs To 165Mpixels/s
Output Screens Resolutions Up to 2.5Mpixel (maximum 2048 pixels in
either direction)
Arbitary Up Scaling 64 x original surface area
Firmware Support Updates supported via USB

Datapath X4 Specifications

General

Number of outputs	4 outputs
AC input voltage	100-240 V
Operating temperature (T-T)	0 - 35 °C
Product color	Black
Output voltage	5 V

Weight and Dimensions

Depth	175 mm
Width	235 mm
Height	44 mm
