SCOPE OF WORK. (Continued)
MATERIALS LIST.
PROVIDED BY DATAREMOTE:
Basic Package Contains (Refer to “What comes in the Box” section)
One (1) DataRemote CDS-9010 device.
One (1) 100-240VAC, 50/60Hz, AC Power Adapter Cord.
One (1) Ethernet Cable RJ-45.
Two (2) Phone Cable RJ-11.
Two (2) Phone Cable RJ-11.
Two (2) LTE antennas (SMA-M connectors)
TOOLS LIST FOR TECH:
Sufficient quantity of dual RJ-45 port surface mount boxes (aka biscuit jack)
Sufficient quantity of RJ-11 or RJ-45 keystone plugs
CAT5E cable – minimum 150'
Power strip (this may not be used, it is in case there are not enough outlets in the room)
Zip Ties / velcro for wire management
Extra RJ-11 cable and RJ-11 male adapters, in the event additional or longer runs are
required.
Mount the biscuit (RJ-11 surface mount) jacks close to the DataRemote CDS-9010 device
that will connect with the remote device.
Connect existing devices to newly installed RJ11 biscuit jacks.
Ensure no "Foreign Voltage" is present by measuring the voltage at the tip and ring
terminals on the new biscuit jacks connected to the devices. Voltage should read: “zero”
volts DC (direct current)
IMPORTANT! IF foreign voltage is present, locate and disable it. IF no foreign
voltage is present, proceed to next step
Connect the DataRemote CDS-9010 device FXS 1-2 (if applicable) jacks to existing devices.
IF Call Box or Voice line, test by making inbound/outbound calls.
IF Call Box also test 'Gate/Door Entry" tone (DTMF / 'Press 9") and programming calls
inbound to the device. Request client or call vendor technical support to facilitate
programming test calls as needed.
If Fire Alarm Panel, test that Fire Alarm Panels primary & secondary lines accordingly,
calling out through the DataRemote CDS-9010 device. If RJ-31 style jack is used, verify that
tip/ring connections are on pins 4 & 5 of jack.
IF FAX, test by sending/receiving FAX using customer equipment (Note: changes may have
to be made to customer equipment ex: ECM on/off)
Call in to remote support team to sign off on install verification
Page 13
Revision No. 004 April 2020
