LED LIGHTS
INDICATORS (continued)
LED STATUS EXPLANATION
WAN ETH
LAN 1
Wi-Fi
PHONE 1
PHONE 2
CELL
OFF
Solid (GREEN)
OFF
Solid (GREEN)
Solid (GREEN)
OFF
Solid (GREEN)
Flashing (GREEN)
OFF
Solid (GREEN)
Flashing (GREEN)
OFF
Strong: All bars solid green
Only three bars Solid green
Two bars are solid green
One bar is solid green
OFF
LTE WAN IP is assigned.
Disconnected
WAN ETH IP is assigned.
Disconnected
Cable connected to the LAN port
The Wi-Fi radio is on
The Wi-Fi radio is off
Registered
On calling / Pick up phone
Not registered
Registered
On calling / Pick up phone
Not registered
RSSI < -50 dBm to -79 dbm
RSSI < -80 dBm to -89 dBm
RSSI < -90 to 100 dBm
RSSI 101 -120 dBm
RSSI 120 dBm and below
CELL DCD
Solid (GREEN)
LAN 2
Solid (GREEN)
Cable connected to the LAN port
TOP PANEL
LED STATUS
Page 6
Revision No. 004 April 2020
