5.3.8 WPS
WPS (Wi-Fi Protected Setup) provides easy procedure to make network connection between wireless station and wireless access point (vigor
router) with the encryption of WPA and WPA2.
It is the simplest way to build connection between wireless network clients and vigor router. Users do not need to select any encryption mode and
type any long encryption passphrase to setup a wireless client every time. He/she only needs to press a button on wireless client, and WPS will
connect for client and router automatically. Press button less than 5s for 2.4GHz, press button between 5 to 10s for 5.0GHz.
WPS Config
If or not enable WPS.
WPS Summary
The status for Current connection,
SSID and so on
WPS Progress
PIN: In the following PIN options, fill
in the PIN code of the client (wireless
card, etc.) that needs to be accessed,
and then click Apply.
PBC: PBC mode There are two ways
to start, you can directly press the PBC
button on the hardware, or select to
PBC mode, and then click Apply.
WPS Status
There are three WPS states:
WSC: Idle state is idle
WSC: Start WSC Process Status is to
start sending messages
WSC: Success: If a client accesses an
AP, the WPS connection succeeds
