Setting Up the VAB-1
The following diagram provides detail about the ports that you will be using on the back of the VAB-1 device as
part of the installation process.
LAN Ports for optional client devices
WAN Port for upstream router devices
Phone ports for analog communication equipment
Power supply to
wall outlet
