Datavan G-615S - G-715 Jumper Settings; CMOS Clear Jumper

26
PRE PARING FOR THE INSTALLATION
JP1 LVDS VOLTAGE SETTING
1 2 3
1-2 = +3.3V
2-3 = +5V
Default = Normal
JP2 Keyboard VOLTAGE SETTING
1 2 3
1-2 = 5VSB
2-3 = +5V
Default = Normal
JP3 CASH DRAWER VOLTAGE SETTING
1 2 3
1-2 = +24V
2-3 = +12V
Default = Normal
JP4 COM 1 D-SUB PIN9 VOLTAGE SELECT
1 3 5
2 4 6
1-2 = 0V / RI
3-4 = +5V
5-6 = +12V
Default = 0V
JP5 COM 2 D-SUB PIN9 VOLTAGE SELECT
1 3 5
2 4 6
1-2 = 0V / RI
3-4 = +5V
5-6 = +12V
Default = 0V
JP6 COM 3 D-SUB PIN9 VOLTAGE SELECT
1 3 5
2 4 6
1-2 = 0V / RI
3-4 = +5V
5-6 = +12V
Default = 0V
JP7 COM 4 D-SUB PIN9 VOLTAGE SELECT
1 3 5
2 4 6
1-2 = 0V / RI
3-4 = +5V
5-6 = +12V
Default = 0V
JRTC1 CMOS CLEAR JUMPER
1 2 3
1-2 = Normal
2-3 = CMOS clear
Default = Normal
