9ROWDJH2XWSXW'H¿QLWLRQ
G-615 / G-715
Connector with Voltage Output Location Power Support
COM 1 for extension interface (9
th
PIN of DB-9) Main Board
DC5V/DC12V
VHOHFWE\MXPSHU
COM 2 for extension interface (9
th
PIN of DB-9) Main Board
DC5V/DC12V
VHOHFWE\MXPSHU
COM 3 for extension interface (9
th
PIN of DB-9) Main Board
DC5V/DC12V
VHOHFWE\MXPSHU
COM 4 for extension interface (9
th
PIN of DB-9) Main Board
DC5V/DC12V
VHOHFWE\MXPSHU
COM 5 for RS-232 POS input device
Signal Convergence
Board
DC5V only
COM 6 for Cash Drawer Main Board
DC12V/ DC24V
VHOHFWE\MXPSHU
Standard USB2.0 Ports
Main Board, Signal
Convergence Board;
Power Switch Board
DC5V / 500mA
G-615S
Connector with Voltage Output Location Power Support
COM 1 for extension interface (9
th
PIN of DB-9) Main Board
DC5V/DC12V
VHOHFWE\MXPSHU
COM 2 for extension interface (9
th
PIN of DB-9) Main Board
DC5V/DC12V
VHOHFWE\MXPSHU
COM 3 for extension interface (9
th
PIN of DB-9) Main Board
DC5V/DC12V
VHOHFWE\MXPSHU
COM 4 (reserved) Main Board N/A
COM 5 (reserved) Main Board N/A
COM 6 for RS-232 POS input device
Signal Convergence
Board
DC5V only
Standard USB2.0 Ports
Main Board, Signal
Convergence Board;
Power Switch Board
DC5V / 500mA
