Device Specifications
Processor for payment and
security functions
ARM Cortex® M3 Security Microcontroller
Memory
• 64KB Internal ROM
• 256KB Internal RAM
• 1MB Internal Flash
Application Memory
4MB Serial Flash
Processor for Android OS
Cores: 8x ARM Cortex A53, Octa-core CPU, Clock Speed: 1.8 GHz, Architecture: 64-bit
GPU
Qualcomm® Adreno™ 506 graphics processing unit (GPU) with 64-bit addressing
Memory
• 16GB Flash
• 2GB LPDDR3 RAM
Main Display
• Type - IPS
• Colors - 16.7M
• Size 5 inch
• Resolution - 720 x 1280
• Backlight
• Capacitive touchscreen
Smart Card Reader
ISO7816, EMV L1 certified
Contactless Card Reader
for payment applications
• AMEX ExpressPay
• Discover D-PAS
• MasterCard Contactless
• VISA PayWave
• China Union Pay
• JCB
Contactless Card Reader
• NFC-A/ISO 14443 Type-A
• NFC-B/ISO 14443 Type-B
• NFC-F/Felica
• NFC-V/ISO 15693
Barcode Reader (option)
• Zebra SE4100* – Image Sensor 1280 x 800 pixels, High Performance 2D Imager Scan Engine
Supported Barcode Types*
• 1D Barcode Scanner Supported Symbologies:
JAN/UPC/EAN incl. add on, Codabar/NW-7, Code 11, Code 39, Code 93, Code 128, GS1-128 (EAN-128), GS1
DataBar (RSS), IATA, Industrial 2of5, Interleaved 2of5, ISBN-ISSN-ISMN, Matrix 2of5, MSI/Plessey, S-Code,
Telepen, Tri-Optic, UK/ Plessey
POSTAL CODE: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX)
• 2D Imager Supported Symbologies:
PDF417, MicroPDF417, Datamatrix, QR Code, Micro QR Code, Aztec, RSS, Composite, TLC-39, MaxiCode
Battery
Rechargeable lithium-Polymer battery 3.7V, 2200 mAh
Connectivity
• USB
- Device
• USB pass-through Docking station
• WLAN
- 2.4G/5G, 802.11 a/b/g/n/ac
• Wireless mobile Data – SC600Y-EM (EMEA)
- LTE FDD: B1/B2/B3/B4/B5/B7/B8/B20/B28
- LTE TDD: B38/B39/B40/B4
- WCDMA: B1/B2/B4/B5/B8
- GSM: 850/900/1800/1900MHz
