Vacuum cleaner (optional)
5
Setup instructions neo
1.21
DATRON AG
5-1
5 Vacuum cleaner (optional)
Description
The vacuum cleaner can be moved and is installed ready to use. A
separate power circuit is required for operation.
Connection
The vacuum cleaner is connected to the machine for suction with
the hose included with it.
The vacuum cleaner is actuated by the machine software after
connection with a cable included with it.
Technical Data
Vacuum cleaner
Technical Data
Dimensions LxWxH (mm)
544 x 456 x 600
Weight
40 kg
Power
1.1 kW
Voltage
100-230V
Negative pressure
2100 Pa
Air output max.
285 m³/h
Sound level
<66 dB(A)
Volume
18 l
Filter category
H10
