4: Technical Description
PRC-BC4-MS 4-11
Table 4-2 Display Board Parts List (PRC-BC4DIS Rev. F)
Designator Part Number Description
C1 241020 “CAP, 2.2UF, TA, 16V, 20%, DIP, 0.1LS”
D1 320002 “DIODE, 1N4148/1N4150 DO-35”
D10 320002 “DIODE, 1N4148/1N4150 DO-35”
D11 320002 “DIODE, 1N4148/1N4150 DO-35”
D12 320002 “DIODE, 1N4148/1N4150 DO-35”
D13 320211 “DIODE, 1N6283A 28V TVS DO-204”
D14 320416 “LED, GREEN 28D T1-3/4”
D15 320415 “LED,RED”
D16 320417 “LED,YELLOW”
D17 320416 “LED, GREEN 28D T1-3/4”
D18 320415 “LED,RED”
D19 320417 “LED,YELLOW”
D2 320002 “DIODE, 1N4148/1N4150 DO-35”
D20 320416 “LED, GREEN 28D T1-3/4”
D21 320415 “LED,RED”
D22 320417 “LED,YELLOW”
D23 320416 “LED, GREEN 28D T1-3/4”
D24 320415 “LED,RED”
D25 320417 “LED,YELLOW”
D26 320416 “LED, GREEN 28D T1-3/4”
D3 320002 “DIODE, 1N4148/1N4150 DO-35”
D4 320002 “DIODE, 1N4148/1N4150 DO-35”
D5 320002 “DIODE, 1N4148/1N4150 DO-35”
D6 320002 “DIODE, 1N4148/1N4150 DO-35”
D7 320002 “DIODE, 1N4148/1N4150 DO-35”
D8 320002 “DIODE, 1N4148/1N4150 DO-35”
D9 320002 “DIODE, 1N4148/1N4150 DO-35”
PL1 610144 “HEADER,MLX,10PIN,.100”
Q1 310057 “XISTOR,NPN,PN2222A,TO92”
Q2 310057 “XISTOR,NPN,PN2222A,TO92”
Q3 310057 “XISTOR,NPN,PN2222A,TO92”
