4: Technical Description
4-12 PRC-BC4-MS
Q4 310057 “XISTOR,NPN,PN2222A,TO92”
R1 137332 “RES,3.3K OHM 1/2W 1% MF”
R10 137272 “RES, 2.7K OHM 1/2W 5% CF”
R11 124103 “RES, 10K OHM, 1/4W, 5%, CF”
R12 137332 “RES,3.3K OHM 1/2W 1% MF”
R13 124182 “RES, 1.8K OHM, 1/4W, 5%, CF”
R14 137272 “RES, 2.7K OHM 1/2W 5% CF”
R15 124103 “RES, 10K OHM, 1/4W, 5%, CF”
R16 137332 “RES,3.3K OHM 1/2W 1% MF”
R17 124182 “RES, 1.8K OHM, 1/4W, 5%, CF”
R2 137272 “RES, 2.7K OHM 1/2W 5% CF”
R3 124103 “RES, 10K OHM, 1/4W, 5%, CF”
R4 137332 “RES,3.3K OHM 1/2W 1% MF”
R5 124182 “RES, 1.8K OHM, 1/4W, 5%, CF”
R6 137272 “RES, 2.7K OHM 1/2W 5% CF”
R7 124103 “RES, 10K OHM, 1/4W, 5%, CF”
R8 137332 “RES,3.3K OHM 1/2W 1% MF”
R9 124182 “RES, 1.8K OHM, 1/4W, 5%, CF”
U1 330007 “IC, LM340T-12 VREG 12V 1A TO-220”
Table 4-2 Display Board Parts List (PRC-BC4DIS Rev. F)
Designator Part Number Description
