Maintenance M7/M7L/M7LT Modular Satellite Modem
3-52 M7/M7L/M7LT - Rev. 0.05
Demodulator Parameters
Representation
Type
Entry
Description
Feature FEC
Vit TCM RS L16k T16k
Read
Only
Shows the FEC capability of the
modem
Feature Activation
00000000000000000000
Numeric
20 characters
Allows entry of a Feature code to
activate new features.
Table 3-8 – Synchronous Interface Parameter Detail
Synchronous Interface Parameters
Representation
Type
Entry
Description
Status I/O
Online
Read Only
N/A
Interface Status
Status I/O Send Clock
Locked, Ok
Read Only
N/A
Status I/O Send Data
Active, Ok
Read Only
N/A
Status I/O Rcv Buffer
100%, 0 Slips
Read Only
Press “1” then "Enter" to
re-center the buffer.
Press “0” then "Enter" to
clear the “Slip Status”.
Only shows if the Rcv Buffer is
active. 100% is buffer center.
Status I/O Rcv Data
Active, Ok
Read Only
N/A
Status I/O Signaling
rts CTS DCD dtr DSR
Read Only
N/A
Synchronous Interface signaling
status. Lower case indicates not-
active status, upper case
indicates active status
Status ESC Signaling
rts CTS DCD dtr DSR
Read Only
N/A
Engineering service channel
interface signaling status. Lower
case indicates not-active status,
upper case indicates active
status. Only shown when the
ESC channel is active.
Status Test
BER Active
Read Only
N/A
Interface Test status
Status Hardware Type
Multi-Sync Interface
Read Only
N/A
Indicates the type of the active
interface
Status Hardware ID
M709013A-1r1.00
Read Only
N/A
Indicates the part number of the
active interface
Status Hardware S/N
101678
Read Only
N/A
Indicates the serial number of the
active interface
I/O Mode
RS-449
Selection
0 = Disable
1 = RS-232
2 = RS-449
3 = RS-449/Unterm
4 = V.35
5 = X.21
6 = EIA-530
7 = EIA-530A
Interface electrical mode.
