Datum Systems M7LT Series - Table 3-6 - Modulator Parameter Detail

M7/M7L/M7LT Modular Satellite Modem Maintenance
M7/M7L/M7LT - Rev. 0.05 3-41
Unit Parameters
Representation
Type
Entry
Description
Test Admin
Normal
Selection
0 = Normal,
1 = Enable
Normal function is meant for
the typical earth station
operator. Enabling the Test
Admin function is reserved for
depot maintenance.
Feature Unit
None
Read Only
N/A
Shows the option capability of
the modem
Feature Activation
00000000000000000000
Numeric
20 characters
Allows entry of a Feature
code to activate new features.
Table 3-6 - Modulator Parameter Detail
Modulator Parameters
Representation
Type
Entry
Description
Status Carrier
Sending, OK
Read Only
Read Only
Modulator Carrier Status
Status BUC
Normal
Read Only
Read Only
External BUC Status.
M7LT only
Status Interface
Normal
Read Only
Read Only
Transmit Interface Status
Status Test
Normal
Read Only
Read Only
Modulator Test Status
Status BUC Power Option
+48v @ 3.13A
Read Only
Read Only
Installed Internal BUC Power
Supply (M7LT only)
Status HW Type
Std IF Modulator
Read Only
Read Only
Identification of installed
Modulator hardware
Status HW ID
M709002A-1r1.00
Read Only
Read Only
Part number of installed
Modulator hardware
Status HW S/N
100032
Read Only
Read Only
Serial number of installed
Modulator hardware
IF BUC Xmt Frequency
14132.000MHz
Numeric
Can change depending on
the setting of the BUC LO
RF carrier center frequency
based on the BUC LO
Frequency parameter setting
IF Frequency
70.000000MHz
Numeric
50.000000 to 180.000000
MHz
950.000000 to 2150.000000
MHz for L-Band unit
Transmit carrier center
frequency
IF BUC Xmt Level
+10dBW
Numeric
Can change depending on
the setting of the BUC Xmt
Gain
Transmit output power level
display based on the BUC Xmt
Gain parameter setting
IF Level
–3.82dBm
Numeric
+5.0 to –35.0 dBm
+3.0 max at 50Ω
Transmit output power level
IF Output
Enabled
Selection
0 = Disable, 1 = Enable
Transmit carrier output enable
