M7/M7L/M7LT Modular Satellite Modem Maintenance
M7/M7L/M7LT - Rev. 0.05 3-61
Alarm Send Data Idle
30 Sec.
Sets the time before an alarm is
raised after there is no data
detected at the Tx interface. (0 =
Disable)
Alarm Rcv Data Mask
to Alarm A
0 = None, 1 = to Alarm A,
2 = to Alarm B,
3 = to Alarm A & B
Selects destination of alarm
Alarm Rcv Data Idle
30 Sec.
Sets the time before an alarm is
raised after there is no data
detected at the Rcv interface. (0
= Disable)
Alarm Backward Mask
to Alarm A
0=None, 1=to Alarm A,
2=to Alarm B,
3=to Alarm A & B
Selects destination of alarm
Alarm Ref Relay Mask
to Alarm A
0=None, 1=to Alarm A,
2=to Alarm B,
3=to Alarm A & B
(Future Option) Selects
destination of alarm
Alarm Test Active Mask
to Alarm A
0=None, 1=to Alarm A,
2=to Alarm B,
3=to Alarm A & B
Selects destination of alarm
Alarm Hardware Mask
to Alarm A
0=None, 1=to Alarm A,
2=to Alarm B,
3=to Alarm A & B
Selects destination of alarm
Test Sat WAN Loopback
Disabled
0 = Disabled, 1 = Enabled
Interface satellite loop-back
receive output to send input
Test Ter WAN Loopback
Disabled
0 = Disabled, 1 = Enabled
Interface terrestrial loop-back
send input to receive output.
Test Ter HDLC Loopback
Disabled
0 = Disabled, 1 = Enabled
Interface terrestrial loop-back
send input to receive output.
Feature PPS Limit
10.000 kPPS
IP Packet per Second limitation
setting.
Feature Activation
00000000000000000000
Allows entry of a Feature code to
activate new features.
Table 3-10 – E7- Express Ethernet Interface Parameter Detail
Status Port 1
Connected, 1 Gb
Status Port 2
Connected, 100 Mb Fdx
