Maintenance M7/M7L/M7LT Modular Satellite Modem
3-70 M7/M7L/M7LT - Rev. 0.05
G7 Interface Parameters
Representation
Type
Entry
Description
Send Mux Mode
Advanced
Selection
0 = Disabled
1 = Advanced
2 = IBS Custom
Enables Multiplexer to specified
mode. Enable makes other menu
selection below visible
Send Mux MCC Rate
0.300 kbps
Numeric
0.000 = Disable
0.300 to 29428.110 kbps
Only in Custom or Advanced
Mode.
Selects framing resources
committed to (MCC) Modem
Control Communications
Send Mux Alarm Channel
Disabled
Selection
0 = Disabled, 1 = Enabled
Enable the backward alarms
Send Mux Overhead Ratio
16379:16384
Read Only
N/A
Shows current data-to-aggregate
ratio for mux
Rcv Mux Mode
Advanced
Selection
0 = Disabled
1 = Advanced
2 = IBS Custom
Enables Demultiplexer to
specified mode.
Any selection other than
Disabled makes other menu
selection below visible
Rcv Mux MCC Rate
0.300 kbps
Numeric
0.000 = Disable
0.300 to 29428.110 kbps
Only in Custom or Advanced
Mode.
Selects framing resources
committed to (MCC) Modem
Control Communications.
Rcv Mux Alarm Channel
Enabled
Selection
0 = Disabled
1 = Enabled
Enable the backward alarms
Rcv Mux Overhead Ratio
16384:16379
Read Only
N/A
Shows current data-to-aggregate
ratio for mux
ESC Async Mode
Auto Overhead Rate
Selection
0 = Disable
1 = Auto Overhead Rate
2 = Manual Overhead
Rate
Activates the ESC Port on the
rear panel for Auto or Manual
baud rate
Any selection other than
Disabled makes other menu
selection below visible
ESC Async Port
RS-232
Selection
0 = RS-232,
1 = RS-485 2 wire,
2 = RS-485 4 wire,
3 = RS-485 Drvr On
Interface type of the ESC port on
the rear panel.
ESC Async Rate
9.600 kbps
Numeric
0.300 – 1000.000 kbps
Baud rate at the ESC port on the
rear panel.
ESC Async Format
N,8,1
Selection
0 = N,7,1,
1 = P,7,1
2 = N,8,1
3 = P,8,1
Format of the ESC port on the
rear panel
ESC Async CTS
Normal
Selection
0 = Normal
1 = Force Active
ESC CTS line control
ESC Async DCD
Normal
Selection
0 = Normal, 1 = Force
Active
ESC DCD line control
