Dashboardwindows
watt
Theheartratedisplaystheheartrate.Whenonlytheupwardpointingarrowis
displayedinthemiddle,thenthismeansthattheheartrateistoolowtoensure
aneffectivetraining.Inversely,whenonlythedownwardpointingarrowis
displayedthentheheartrateistoohigh.Ifthearrowstartsblinkingthenthe
loadistoohighandtheusershouldmoderatethetraining.
Speedanddistancewindow:thiswindowshowstheactualspeedorthe
correspondingdistancecovered.Pressingthecontrolbuttonswitchesback
andforthbetweenthesetwovalues.Seepage5.
TheRPMdisplayindicatesthevelocityinrevolutionsperminute.
(+=pedalfaster,-=pedalslower)
Thewattwindowshowstheloadinwatt.Thedisplayedwattvaluewillblinkto
indicatereachingeitherthewattloadlimitofthedeviceorthewattloadlimitof
theuser.Italsoshowstherelaxvaluewithrelaxationexercises.
Youcanindividuallysetupwhichdatayouwhishtoview:clock,trainingtime,
speed,distanceordissipatedenergy(inkJoule).Youcanswitchbackandforth
withaseconddisplaybypressingthecontrolbutton.Seepage5
Theuserspecifiestheusernumber(1to4orguest0)
Thegraphicscreendisplaystheprograms.Theload(inwatt)isshownonthe
scaleontheleftsideofthescreen.Thetrainingtimeisshownontheloweraxis.
Inheartratecontrolledprogramsthesystemdisplayse.g.100beatsperminute
atthe200wattpositiononthescreenscale.
Intheheightprofileprogramsthetimeaxisindicatesthedistanceinkmwhile
thewattaxisindicatestheheightprofile.
Note:theillustrationsmaybechangedwithoutnotice!
