Davis Instruments Vantage VUE User Manual

13
Contacting Davis Technical Support
For questions about installing or operating your Vantage Connect,
please contact Davis Technical Support. We’ll be glad to help.
Specifications
Cellular Bands . . . . . . . . . . . . . . . . . . . . . . . . . . 850, 900, 1800, 1900 MHz
Operating Temperature. . . . . . . . . . . . . . . . . . . . -40° to +140°F (-40° to +60°C)
Charging Temperature . . . . . . . . . . . . . . . . . . . . -4° to +120°F (-20° to +49°C)
Storage Temperature . . . . . . . . . . . . . . . . . . . . . -40° to +140°F (-40° to +60°C)
Current Draw . . . . . . . . . . . . . . . . . . . . . . . . . . . 25mA typical, 1A peak
GPRS class 10: 146mA typical
Transmitter Power . . . . . . . . . . . . . . . . . . . . . . . 2W @ 850/900 MHz (Class 4)
1W @ 1800/1900 MHZ (Class 1)
Transmission frequency: North America . . . . . . 902 - 928 MHz FHSS
EU, UK, and OV models . . . . . . . . . . . . . . . . . . . 868.0 -868.6 MHz FHSS, power
output less than 10mW
Housing Material. . . . . . . . . . . . . . . . . . . . . . . . . Rugged ASA Plastic
Dimensions (width x length x height). . . . . . . . . . 13.75 X 10 X 4.15 inches
(34.9 X 25.4 X 10.5 cm)
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8.14 lbs. (3.69 kg)
Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 volt, 12 Ah, gel cell with quick
disconnect 0.250” x 0.032” (6.35
mm x 0.81 mm) tabs
Dimensions without tabs . . . . . . . . . . . . . . . . . . . 5.95” L x 3.70” H x 2.00” D;
151 mm L x 98 mm H x 51 mm D
Certifications: . . . . . . . . . . . . . . . . . . . . . . . . . .FCC PTCRB CE Carrier
Online www.davisnet.com
See the Weather Support section for copies of user
manuals, product specifications, application notes,
software updates, and more.
E-mail support@davisnet.com
Telephone (510) 732-7814
Monday - Friday, 7:00 a.m. - 5:30 p.m. Pacific Time.

Davis Instruments Vantage VUE Specifications

General

Console Display Type	LCD
Wind Direction Range	0 to 360°
Wind Direction Accuracy	±3°
Temperature Accuracy	±1°F (±0.5°C)
Humidity Accuracy	±3%
Solar Radiation Range	0 to 1800 W/m²
Solar Radiation Accuracy	±5%
UV Index Range	0 to 16
Wireless Transmission Range	1000 feet (300 meters)
Update Interval	2.5 seconds
Temperature Range	-40°F to +150°F (-40°C to +65°C)
Humidity Range	0 to 100% RH
Rain Collector Resolution	0.01 inches (0.2 mm)
Wind Direction Resolution	1°
Power Source (Integrated Sensor Suite)	Solar panel with battery backup
Power Source (Console)	AC adapter or 3 C batteries
Wind Speed Accuracy	±2 mph (±3 kph) or ±5%, whichever is greater
Rainfall Accuracy	±4%
Operating Temperature	-40°F to +140°F (-40°C to +60°C)
Wind Speed Range	0 to 150 mph (0 to 241 km/h, 0 to 67 m/s)
