5
Connect the battery
The Vantage Connect is shipped with one battery cable (the red, or positive cable)
disconnected to prevent battery drain. Connect the red cable to the red terminal.
Note: IMPORTANT: When putting your Vantage Connect into cold storage, disconnect the
red cable.
Install the Vantage Connect
If you have not already set up your ISS or additional station, do so first. (See the
instruction manual that came with your ISS or additional station.)
Mount the Vantage Connect shelter
Tip: Mounting the shelter may be easier if done by two people.
Choose a location for your Vantage Connect. It can be mounted on a pole or a flat
surface such as a wall or a wooden post. The shelter should be mounted within
transmission range of your ISS. (Maximum of 1000 feet (300 m), line-of-sight,
open air.)
It is important that the shelter be mounted so that the solar panel gets the greatest
amount of sunshine -- the solar shelter should be facing south (in the Northern
Hemisphere) or north (in the Southern Hemisphere).
Tip: While south is generally appropriate for the Northern Hemisphere (and north in the
Southern Hemisphere), your goal is to maximize direct sunlight on the solar panel. If
your location does not have a full sunrise-to-sunset exposure arc when the panel
faces south, you should face your solar panel toward a point midway in the existing
arc to maximize panel charging.

Davis Instruments Vantage VUE Specifications

General

Console Display Type	LCD
Wind Direction Range	0 to 360°
Wind Direction Accuracy	±3°
Temperature Accuracy	±1°F (±0.5°C)
Humidity Accuracy	±3%
Solar Radiation Range	0 to 1800 W/m²
Solar Radiation Accuracy	±5%
UV Index Range	0 to 16
Wireless Transmission Range	1000 feet (300 meters)
Update Interval	2.5 seconds
Temperature Range	-40°F to +150°F (-40°C to +65°C)
Humidity Range	0 to 100% RH
Rain Collector Resolution	0.01 inches (0.2 mm)
Wind Direction Resolution	1°
Power Source (Integrated Sensor Suite)	Solar panel with battery backup
Power Source (Console)	AC adapter or 3 C batteries
Wind Speed Accuracy	±2 mph (±3 kph) or ±5%, whichever is greater
Rainfall Accuracy	±4%
Operating Temperature	-40°F to +140°F (-40°C to +60°C)
Wind Speed Range	0 to 150 mph (0 to 241 km/h, 0 to 67 m/s)
