DAVIS Vantage Pro2 Specifications

9
Wireless Vantage Pro2
™
Sensor Charts
Package Dimensions
Product #
Package Dimensions
(Length x Width x Height)
Package Weight UPC Codes
6152
6152EU
6152UK
17.0" x 11.0" x 13.0"
(410 mm x 264 mm x 330 mm)
12.8 lbs. (5.8 kg)
011698 00229 0
011698 00347 1
011698 00348 8
6162
6162EU
6162UK
13.3 lbs. (6.0 kg)
011698 00306 8
011698 00307 5
001698 00308 2
6153
6153EU
6153UK
15.0" x 13.0" x 24.0"
(378 mm x 327 mm x 594 mm)
12.8 lbs. (5.8 kg)
011698 00335 8
011698 00336 5
001698 00337 2
6163
6163EU
6163UK
13.3 lbs. (6.0 kg)
011698 00341 9
011698 00342 6
001698 00342 3
Temperature Accuracy
0.0
1.0
2.0
3.0
4.0
5.0
-40 -20 0 20 40 60 80 100 120 140
Temperature (°F)
Temperature Accuracy
0.0
0.5
1.0
1.5
2.0
2.5
3.0
3.5
4.0
4.5
5.0
-40 -30 -20 -10 0 10 20 30 40 50 60
Temperature (°C)
Accuracy (°F) Accuracy (°C)
Figure 1. Temperature Accuracy
Rain Rate Resolution
Low Range
Resolution (in.)
10.0
1.00
0.10
0.01
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
Rain Rate (in/hr.)
Rain Rate Resolution
Full Range
Resolution (in.)
100.00
10.00
1.00
0.10
0.01
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
Rain Rate (in/hr.)
Figure 2. Low Range Rain Rate Resolution
Figure 3. Full Range Rain Rate Resolution

DAVIS Vantage Pro2 Specifications

General

Update Interval	2.5 seconds
Temperature Accuracy	±1°F (±0.5°C)
Barometric Pressure Range	16.00 to 32.50 inHg (540 to 1100 hPa)
Rain Collector Type	Tipping bucket
Wind Speed Range	0 to 200 mph (0 to 322 km/h)
Wind Speed Accuracy	±2 mph (±3 km/h) or ±5%, whichever is greater
Wind Direction Resolution	1°
Wind Direction Accuracy	±3°
Solar Radiation Range	0 to 1800 W/m²
Solar Radiation Sensor Accuracy	±5%
UV Index Range	0 to 16
UV Index Accuracy	±5%
Wireless Transmission Range	Up to 1000 ft (300 m)
Temperature Range	-40°F to +150°F (-40°C to +65°C)
Humidity Range	0 to 100%
Humidity Accuracy	±3%
Rain Collector Resolution	0.01 in (0.2 mm)
Rain Measurement Accuracy	±4%
Wind Direction Range	0 to 360°
Power Supply	Solar powered with battery backup
