DAVIS Vantage Vue 6250 User Manual

7
Package Dimensions
Product #
Package Dimensions
(Length x Width x Height)
Package Weight UPC Codes
6250
Complete Station
18.25" x 7.25" x 15.25"
(46.4 cm x 18.4 cm x 18.7 cm)
6.88 lbs
(3.12 kg)
0 11698 00912 1
6351
Console
8.0" x 8.0" x 4.0"
(20.3 cm x 20.3 cm x 10.1 cm)
1.76 lbs
.80 kg
0 11698 00913 8
6357
ISS
18.25" x 7.25" x 15.25"
(46.4 cm x 18.4 cm x 38.7 cm)
5.44 lbs
(2.47 kg)
0 11698 00914 5

DAVIS Vantage Vue 6250 Specifications

General

Rain Collector	Self-emptying tipping bucket
Type	Wireless
Frequency	868 MHz
Transmission Range	up to 300 meters (1000 feet) line of sight
Temperature Range	-40 to 65 °C (-40 to 149 °F)
Humidity Range	0 to 100% RH
Wind Speed Range	0 to 200 mph (0 to 322 kph)
Wind Direction Range	0 to 360 degrees
Wind Speed Accuracy	+/- 2 mph (+/- 3 km/h) or +/- 5% , whichever is greater
Wind Direction Accuracy	±3°
Rainfall Resolution	0.01 in (0.2 mm)
Rainfall Range	0 to 9999.9 mm
Rain Measurement Accuracy	±4%
Power Supply	Solar panel with battery backup
Battery Life	Approximately 1 year
Console Display	LCD
Power (Console)	AC adapter or 3 C-cell batteries
Update Interval	2.5 seconds
Temperature Accuracy	±0.5 °C
Humidity Accuracy	±3%
Operating Temperature	-40 to 65 °C (-40 to 149 °F)
