Issued: 28.02.2005
Strider MD 4 Plus
Remove the frames (11) upwards from
the holding bolts (12) on the drive unit.
➨
Separating the chassis
NOTE
Use rear bumper as grip
to stowe the drive unit.
Open the clamping bolt clamping lever
(15) and fold the clamping bolt upwards.
➨
Unlocking the drive unit
Tilt drive unit to the rear onto the anti
tipp wheels (16).
➨
Tilt the drive unit away
Transporting the Strider
