Days MD 4 Plus - Removing the Batteries; Folding the Tiller down; Disengaging the Drive Unit from the Chassis

54
Issued: 28.02.2005
Strider MD 4 Plus
Separate the front unit connecting plug
(11).
➨
Push or pull the locking lever (9) and
fold the tiller to the rear (10) until it is
horizontal.
➨
Folding the tiller down
Separating the front
connector
13.3.5 Folding the tiller down
13.3.6 Disengaging the drive unit from
the chassis
Remove the battery belts (8).
Remove the batteries.
➨
➨
Removing the batteries
Press the locking device on the plug and
disconnect the connecting plugs (6 + 7)
on the battery cable.
➨
13.3.4 Removing the batteries
Transporting the Strider
