DB ELETTRONICA TELECOMUNICAZIONI S.p.A.
PM 1000 – 1 kW FM Broadcasting Transmitter - USER’S MANUAL
15 /101
9 - Select 0.72 - 0.64 = 0.08 MHz, there is a weight equal to 0.08 MHz, so put in OFF position the
corresponding switch to complete the setting.
The final configuration is:
10 - Adjust the desired output power using the “PWR” front panel potentiometer.
