DB ELETTRONICA TELECOMUNICAZIONI S.p.A.
PM 1000 – 1 kW FM Broadcasting Transmitter - USER’S MANUAL
44 /101
5.5 POWER SUPPLY PART LIST
ITEM QUANTITY REFERENCE PART
1 1 CN1 MSQ02001 MSQ02001
2 2 CN3,CN2 MSQ03001 MSQ03001
3 2 C1,C11 3.3nF CP_A
4 1 C2 1µF 50V CE_A
5 4 C3,C15,C16,C17 100µF 25V CE_E
6 2 C12,C4 470µF 63V ROE CE_D
7 2 C14,C5 220nF CP_B
8 1 C6 330µF 35V ROE CE_B
9 1 C7 220nF CP_B
10 1 C8 220pF CC_A
11 1 C9 22nF CP_A
12 1 C10 220nF CP_A
13 1 C13 330µF 35V CE_B
14 4 C18,C20,C21,C23 100nF CC_B
15 2 C19,C22 10µF 35V CE_A
16 4 D1,D3,D4,D5 SB360 D2
17 2 D7,D2 LED VERDE LED_3MM
18 1 D6 1N4007 1N4007
19 1 D8 1N5819 1N5819
20 1 L1 270µH IND_TOR
21 2 L2,L4 150µH IND_TOR_P
22 1 L3 150µH IND_TOR
23 1 R1 20K R1/4W
24 1 R2 10K R1/4W
25 2 R3,R8 2K2 R1/4W
26 1 R4 9K1 1% R1/4W
27 2 R5,R10 1K TRIM_PTH_V
28 1 R7 3K3 R1/4W
29 1 R9 8K2 R1/4W
30 1 R11 1K R1/4W
31 1 U1 L4971 DIP8
32 1 U2 LM2591 TO-220-5PIN
33 1 U3 7805 78XXTO220
34 1 U4 7905 79XXTO220
To Next Page
