DB ELETTRONICA TELECOMUNICAZIONI S.p.A.
PM 1000 – 1 kW FM Broadcasting Transmitter - USER’S MANUAL
42 /101
5.4 0601-008 POWER SUPPLY BOARD
The protection and measure boards are supplied with an independent power supply boards that
furnish the +/- 12 Volts and +/- 5 Volts to the two boards. It is positioned near the display board.
Fig. 5.4 – POWER SUPPLY FOR MEASURE BOARD LAYOUT (DB 0601_008)
