DB ELETTRONICA TELECOMUNICAZIONI S.p.A.
PM 1000 – 1 kW FM Broadcasting Transmitter - USER’S MANUAL
40 /101
PROTECTION
Overload 110 - 150% rated output power
Over voltage 27.6 – 32.4 V
Protection type: Hiccup mode, recovers
automatically after fault condition is removed
ENVIRONNEMENT
Working temperature -25 ÷ +70°C
Working humidity 20 – 90 % RH not condensing
Storage temperature, humidity -40 ÷ +85 °C, 10 ÷ 95% RH
Temp. Coefficient ±0.03%/°C (0÷50°C)
Vibration 10 – 500 Hz, 5G 10min/1cycle, period for 60 min.
each along X,Y,Z axes
OTHERS
MTBF 265 Khrs min
Dimension 129/97/38 mm (L/W/H)
Weight 0.41 kg
