560A
Specifications
INPUT
Type: Electronically balanced/unbalanced, RF filtered
Impedance: 40kΩ balanced, 20kΩ unbalanced
Maximum Input Level: +22dBu
CMRR: >40 dB; typically >55 dB at 1 kHz
OUTPUT
Type: Electronically balanced/unbalanced, RF filtered
Impedance: Balanced 30Ω, unbalanced 15Ω
Maximum Output Level: + 22 dBu
PERFORMANCE
Frequency Response: 20 Hz – 20 kHz, + 0/-0.5 dB
0.5 Hz – 100 kHz, +0/-3 dB
Noise: <-97 dBu, Unweighted (22 Hz – 22 kHz)
THD+N: <0.005% typical, No compression, 1 kHz input at 0 dBu
<0.07% typical, Any Amount of Compression up to 40 dB @ 1 kHz
Dynamic Range >119 dB
COMPRESSION
Gain Adjustment Range: Variable from -20 dB to +20 dB
Threshold Range: -40 dBu to +20 dBu
Threshold Characteristic: Selectable OverEasy® or Hard Knee
Compression Ratio: Variable 1:1 to ∞:1 thru to -1:1; 60dB Maximum Compression
Attack Time: Program-Dependent; Typically 15ms for 10dB, 5ms for 20dB, 3ms for 30dB
Release Time: Program-Dependent; Typically 8ms for 1dB, 80ms for 10dB,
400ms for 50dB; 125dB/Sec Rate
POWER
Requirements: +/- 16VDC
Current Draw: 60mA per power rail
Power Draw: 1.92 watts
PHYSICAL
Rack System: 500 Series Compatible Power-frame
Rack Space 1 Slot
Dimensions (H x W x D) 5.25” x 1.5” x 6” (13.34cm x 3.81cm x 15.24cm)
Weight: 1.3 lbs (0.59 kg)
Shipping Weight: 1.7 lbs (0.77 kg)
Notes: Noise and frequency response specifications are at unity gain.
0dBu=0.775Vrms
Specifications are subject to change without notice.
