STEP 4:
BACKGUARD KITS:
The backguard is located as shown in
Fig. 6. Secure the backguard to the wall
behind the cooktop.
Specific instructions for installation of the
full backguard or low backguard can be
found packaged with the backguard. See
also page 5.
The backguard must be installed when
there is less than a 12" clearance between
combustibles and the back of the cooktop
(above the cooking surface, see Fig. 5,
page10).
BACKGUARD INSTALLATION
11
Fig. 6
Wall Mount
Full Backguard
(Model #’s BGC-3030,
BGC-3036, BGC-3048)
Wall Mount
Low Backguard
(Model #’s BGC-1230,
BGC-1236, BGC-1248)
To Next Page
