PLANNING THE INSTALLATION
5
RECOMMENDED INSTALLATION INSTRUCTION
(If installing a full backguard with the cooktop)
A) Vent Hood
B) Backguard System
C) Cooktop
1) Locate cooktop according to cooktop installation instructions.
2) Measure distance from counter surface to top of trim on cooktop adding 1/8”for backguard
clearance.
3) Transfer this measurement to the wall. This will mark the bottom of your backguard.
4) From this line measure 30-1/16”up wall to mark top of 30” backguard. This is the minimum height
that the bottom of your vent hood can be installed.
6) Follow vent hood manufacturer’s installation instructions to install vent hood.
7) Follow backguard installation instructions to install backguard.
8) Connect gas and electric connections and slide cooktop into position.
