DCS Debussy DAC - Connecting to a Single AES or SPDIF Source

dCS Debussy DAC User Manual Software Issue 2.2x
August 2013
Debussy DAC Manual v2_2x.docx Page 9 English version
Connecting to a Single AES or SPDIF source
Most source equipment (such as a CD transport or DVD player) is fitted with a single wire digital
output, usually on an RCA phono connector.
Figure 2 – Connecting an SPDIF interface.
• Connect your source equipment to the matching input on the DAC’s rear panel using a suitable
cable.
• Press the Input button repeatedly until the AES1, AES2, SPDIF1 or SPDIF2 indicator illuminates
as required.
If the source is active, the DAC will lock to the source and the appropriate sample rate indicator will
illuminate.
Proceed to Step 3.
Analogue outputs
to amplifier
Pa
g
anin
i
Transport
