ddtop TRG808X Series User Manual

6 / 18
WWW.DDTOP.COM
3 Technical Parameters
3.1 Appearance and Parameters
TRG8081
Antenna structure: small lens antenna
Measuring range: 0.08m～10m/0.08m～30m
Power supply: 12～28V DC
Accuracy: ±1mm/±1mm
Beam angle: 8°
Output signal: 4～20mA+HART
RS485+Modbus RTU
Ambient temperature: -40℃～+70℃
IP rating: IP67
Housing material: Aluminum alloy
Process temperature: -40～85℃
Process pressure: -0.1～2.5 MPa
TRG8082
Antenna structure: Standard lens antenna
Measuring range：0.08m～10m/0.08m～30m/
0.3m～60m/0.3m～120m
Power supply: 12～28V DC
Accuracy: ±1mm/±1mm/
±3mm/±5mm
Beam angle: 3°
Output signal: 4～20mA+HART
RS485+Modbus RTU
Ambient temperature: -40℃～+70℃
IP rating: IP67
Housing material: Aluminum alloy
Process temperature: -40～200℃
Process pressure: -0.1～2.5 MPa
TRG8083
Antenna structure: Anti-corrosion antenna
Measuring range：0.08m～10m/0.08m～30m/
0.3m～60m/0.3m～120m
Power supply: 12～28V DC
Accuracy: ±1mm/±1mm
±3mm/±5mm
Beam angle: 3°/8°
Output signal: 4 to 20mA + HART
RS485+Modbus RTU
Ambient temperature: -40℃～+70℃
IP rating: IP67
Housing material: Aluminum alloy
Process temperature: -40～150℃
Process pressure: -0.1～2.5 MPa
