Operating instructions and warnings
14
WARNINGToensureanappropriatelevelofelectricalsafetyalwayskeepthe230Vpowersupply
cablesapartfromlowvoltagecables(motorspowersupply,controls,electriclocks,aerialandauxiliary
circuitspowersupply),andfastenthelatterwithappropriateclampsneartheterminalboards. A4
WARNINGAnyinstallation,maintenanceorrepairoperationonthewholesystemmustbecarried
outexclusivelybyqualifiedpersonnel.Alltheseoperationsmustbeperformedonlyafterdisconnecting
thepowersupply,andoperatinginstrictcompliancewiththeelectricalstandardsandregulationsin
forceinthenationofinstallation. A5
WARNINGInstallthecontrolboardaccordingtotheinstructionsgivenin“F3Installation”.Drill
onlytheholesforeseenbythemanufacturertoallowforwirespassage,andusethespecifiedclamps.
Failuretocomplywiththeseinstructionsmayjeopardizethelevelofelectricalsafety. A6
WARNINGDuringthemotorsstrokememorization,thecontrolboarddetects automaticallythe
presenceandtypeofphotocells,safetydevicesandlimitswitcheswhichareinstalled.Itistherefore
essentialthatduringthisphasethelatterbeproperlyconnectedandworking.In case only one motor
works, P29=1 must be programmed immediately. A7
WARNINGWrongassessmentofimpactforcesmaycauseseriousdamagetopeople,animalandthings.
DEASystemremindsallpersonnelthattheinstallermustascertainthattheseimpactforces,measuredaccording
toEN12445prescriptions,areactuallybelowthelimitsindicatedbyEN12453regulation. A 8
WARNINGAnyexternalsafetydeviceinstalledinordertoconformtothelimitssetforimpactforces
mustcomplywithEN12978. A9
WARNINGUsingsparepartsnotindicatedbyDEASystemand/orincorrectre-assemblymayen-
dangerpeople,animalsandproperty,andmayalsocausemalfunctioningoftheproduct:alwaysuse
partsprovidedbyDEASystemandfollowassemblyinstructions. A10
WARNINGDisposalofpackagingmaterials(suchasplastic,cardboard,etc.)mustbedoneaccordingto
regulationsinforcelocally.Donotleaveplasticbagsandpolystyrenewithinthereachofchildren A 11
WARNINGDumpingbatteriesintheordinarylitterbinorleavingthemjustanywhereisextremely
dangerousfortheenvironment.Alwaysusethedifferentiatedwastedisposalbinsandcomplywithlocal
regulationsinforce.A12
3 MODELS AND CONTENTS OF THE PACKAGE
Thecontrolboard224RRisavailablealsointhe224RR/Bmodelcompletewithbackupbatteriesin
caseofpowerfailure.
4 PRODUCT DESCRIPTION
224RRcontrolboardhasbeendesignedfortheautomationofswinggatesoperatedby24V 
motors.Itisextremelyversatile,easytoinstallandfullycomplieswithEuropeanregulationsconcerning
electromagneticcompatibilityandelectricsafety
Mainfeaturesoftheproduct:
1. settingallparametersby3keysanda4-digitdisplay;
2. possibilityoffinetuningofmotorspeedbothduringitscompletestrokeandduringthelastphaseofit
(slow-down).Itkeepsmotortorqueevenatverylowspeed;
3. possibilitytosetatwilltheslow-downdurationofeachofthetwomotorsseparately;
4. Internalanti-crashsafetydevicewhosesensitivitycanbeadjusted(accordingtoa70-levelscale)se-
paratelyforthetwomotorsandinbothoperatingdirections;
5. inputs to connect both normal and powered external safety devices (mechanical ribs or photo-
cell barriers), with the possibility to run a self-test before each operation.  Controlled photocells;
6. built-in433,92MHzradioreceiverforbothHCSandHT12Ecodingofferingthepossibilitytosearch
anddeleteeachtransmitterseparately.
