Operating instructions and warnings
15
WARNINGDEASystemremindsallusersthattheselection,positioningandinstallationofallma-
terialsanddeviceswhichmakeupthecompleteautomationsystem,mustcomplywiththeEuropean
Directives2006/42/CE(MachineryDirective),2004/108/CE(electromagneticcompatibility),2006/95/
CE(lowvoltageelectricalequipment).Inordertoensureasuitablelevelofsafety,besidescomplying
withlocalregulations,itisadvisabletocomplyalsowiththeabovementionedDirectivesinallextra
Europeancountries. A1
5 TECHNICAL DATA
Powersupply....................................................230V~+/-10%50Hz
Flashinglightoutput.........................................30V max10Wart.Lumy24S
Auxiliarypowersupplyoutput(+24VAUX)..........24V max200mA
Safetydevicespowersupplyoutput(+24VSIC)...24V max200mA
Electriclockoutput............................................max1electriclockart.110
LC/SCAcontactcapacity...................................max5A
Maxmotorcapacity..........................................2X80Wmax
Protectionlevel.................................................IP54
FuseF1............................................................T2A250V(retarded)
FuseF2............................................................T20A250V(retarded)
Radioreceiverfrequency...................................433,92MHzrollingcode/dipswitchcoding
Max.numberoftransmittercontrolled................100
6 OPERATING CONDITIONS
224RRcontrolboardisdesignedfortheautomationofswinggatesoperatedby24V motors.
Thiscontrolboardhasbeendesignedandtestedforoperationunder“normal”conditionsforboth
residentialandindustrialuse.Thelevelofprotectionagainstdustandwaterandotherdataareillustrated
in“5TechnicalData”.
WARNINGUsingtheproductunderunusualconditionsnotforeseenbythemanufacturermay
causedangeroussituations;thisisthereasonwhyalltheconditionsprescribedintheseinstructions
mustbefollowed. A2
WARNINGUndernocircumstancemusttheproductbeusedinanexplosiveenvironmentorsur-
roundingsthatmayprovecorrosiveanddamagepartsoftheproduct. A3
7 ASSEMBLY AND WIRING INSTRUCTIONS
WARNINGToensureanappropriatelevelofelectricalsafetyalwayskeepthe230Vpowersupply
cablesapartfromlowvoltagecables(motorspowersupply,controls,electriclocks,aerialandauxiliary
circuitspowersupply),andfastenthelatterwithappropriateclampsneartheterminalboards. A4
WARNINGAnyinstallation,maintenanceorrepairoperationonthewholesystemmustbecarried
outexclusivelybyqualifiedpersonnel.Alltheseoperationsmustbeperformedonlyafterdisconnecting
thepowersupply,andoperatinginstrictcompliancewiththeelectricalstandardsandregulationsin
forceinthenationofinstallation. A5
WARNINGInstallthecontrolboardaccordingtotheinstructionsgivenin“F3Installation”.Drill
onlytheholesforeseenbythemanufacturertoallowforwirespassage,andusethespecifiedclamps.
Failuretocomplywiththeseinstructionsmayjeopardisethelevelofelectricalsafety. A6
Connecttothepowersupply230V~±10%50Hzthroughamultipoleswitchoradifferentdevice
thatcanensuremultipoledisconnectionfromthepowersupply,withacontactopeningof3,5mm.Use
acablewithaminimumsectionof3x1,5mm²(e.g.aH07RN-Ftype).
Makeallconnectionstotheterminalboardandremembertoshort-circuit,whenevernecessary,all
unusedinputs.(Seetable1terminalboardconnectionandFig.1basicandcompletewiringdiagram)
