Markers Code no. Description 280 350 430 500 570 650
1043 S103302 Condensate collector strip, 6 sections x x x x x x
1044 S62713 O-ring diameter 20 x 2.5 mm (10 pieces) x x x x x x
1045 S103243 Levelling foot (2 pieces) x x x x x x
1046 S103143 Siphon connection x x x x x x
1047 S103261 Gasket seal 45 x 34 x 3 mm (10 pieces) x x x x x x
1048 S103142 Complete siphon x x x x x x
1049 S103179
Air supply/flue gas adapter diameter 250-200 mm
(accessory)
x x x x x x
1049 7600367 Clamping ring + gasket diameter 200 mm x x x x x x
1050 S103178 Air supply/flue gas adapter, diameter 250 mm x x x x x x
1050 7600368 Clamping ring + gasket seal Ø 250 mm x x x x x x
Tab.42 Heat exchanger and burner C 330 ECO
Markers Code no. Description 280 350 430 500 570 650
2001 S103166 Front section x x x x x x
2002 S103168 Intermediate section x x x x x x
2003 S103167 Rear section x x x x x x
2004 S101003 Temperature sensor NTC (2 pieces) x x x x x x
2005 S103262 Ignition/ionisation electrode x x x x x x
2006 S45004
Flame inspection window 32 x 32 x 3 mm, includ
ing gasket
x x x x x x
2007 S100430 Blank flange, return x x x x x x
2008 S100431 Blank flange, flow x x x x x x
2009 S103263 O-ring diameter 107 mm (4 pieces) x x x x x x
2010 S103264 O-ring diameter 82 mm (8 pieces) x x x x x x
2011 S103265 Cover plate for electric ignition x x x x x x
2012 S62105 Sealing plate for ignition electrode (10 pieces) x x x x x x
2013 S42649 Immersion tube, ½" x x x x x x
2014 S103291 0-10 bar pressure gauge x x x x x x
2015 S103030 Flow pipe, 5 + 8 sections x x
2015 S103031 Flow pipe, 6 + 9 sections x x
2015 S103032 Flow pipe, 7 + 10 sections x x
2016 183 M12 bolt x 40 mm x x x x x x
2017 S103283 Nut flange M12 (10 pieces) x x x x x x
2018 62346 Dowel pin, diameter 12 x 20 mm x x x x x x
2019 57727 Stud M12 x 35 mm x x x x x x
2020 S54822 Flame inspection window holder x x x x x x
2021 S103266 Sealing plate for burner (2 pieces) x x x x x x
2022 S57785 Cover plate for burner hole x x x x x x
2023 S100643 Silicone gasket RTV 106 x x x x x x
2024 S103267 Burner dowel pin (10 pieces) x x x x x x
2025 S103033 Return pipe, 5 + 8 sections x x
2025 S103034 Return pipe, 6 + 9 sections x x
2025 S103035 Return pipe, 7 + 10 sections x x
2026 S103304 Filling and drain valve, 1" x x x x x x
2027 S101368 Silicon seal, red, Ø 7 mm (5 metres) x x x x x x
2028 S57720 Heat exchanger access plate, 5 sections x
2028 S57721 Heat exchanger access plate, 6 sections x
2028 S57722 Heat exchanger access plate, 7 sections x
2028 S57723 Heat exchanger access plate, 8 sections x
2028 S57724 Heat exchanger access plate, 9 sections x
2028 S103148 Heat exchanger access plate, 10 sections x
13 Spare parts
84 7600532 - v.11 - 13122018
