DeDietrich C 330 Series User Manual

Markers Code no. Description 280 350 430 500 570 650
2029 S100549 Stud M8 (25 pieces) x x x x x x
2030 S100556 Nut M8 (25 pieces) x x x x x x
2031 S57738 Return water blind pipe, 5 sections x
2031 S57739 Return water blind pipe, 6 sections x
2031 S57740 Return water blind pipe, 7 sections x
2031 S57741 Return water blind pipe, 8 sections x
2031 S57742 Return water blind pipe, 9 sections x
2031 S103036 Return water blind pipe, 10 sections x
2032 S100532 Plug, ⅜" x x x x x x
2033 S103269 Return water distribution pipe, 5 sections x
2033 S103270 Return water distribution pipe, 6 sections x
2033 S103271 Return water distribution pipe, 7 sections x
2033 S103272 Return water distribution pipe, 8 sections x
2033 S103273 Return water distribution pipe, 9 sections x
2033 S103038 Return water distribution pipe, 10 sections x
2047 S103268 Temperature sensor HI x x x x x x
2048 S103188 Nipple including silicon hose 8 x 2 mm x x x x x x
2049 S103274 Silicone hose 4/8, 1300 mm x x x x x x
2050 S100668
Insulation for heat exchanger front plate, 5 sec
tions
x
2050 S100669
Insulation for heat exchanger front plate, 6 sec
tions
x
2050 S100670
Insulation for heat exchanger front plate, 7 sec
tions
x
2050 S100671
Insulation for heat exchanger front plate, 8 sec
tions
x
2050 S100672
Insulation for heat exchanger front plate, 9 sec
tions
x
2050 S103149
Insulation for heat exchanger front plate, 10 sec
tions
x
2051 S35458 Gasket for flame inspection window (5 pieces) x x x x x x
2052 S48950 Screw M4 x 10 mm DIN 7985 (50 pieces) x x x x x x
2053 S41601 Air vent, ⅛" x x x x x x
2054 S101806 Heat exchanger insulation set, 5 sections x
2054 S101807 Heat exchanger insulation set, 6 sections x
2054 S103307 Heat exchanger insulation set, 7 sections x
2054 S103308 Heat exchanger insulation set, 8 sections x
2054 S103309 Heat exchanger insulation set, 9 sections x
2054 S103310 Heat exchanger insulation set, 10 sections x
2055 7600397 Holding frame x x x x x x
2097 S103039 Second return pipe, 5 + 8 sections x x
2097 S103040 Second return pipe, 6 + 9 sections x x
2097 S103041 Second return pipe, 7 + 10 sections x x
2099 S57743 Second return water pipe, 5 sections x
2099 S57744 Second return water pipe, 6 sections x
2099 S57745 Second return water pipe, 7 sections x
2099 S57746 Second return water pipe, 8 sections x
2099 S57747 Second return water pipe, 9 sections x
2099 S103037 Second return water pipe, 10 sections x
2100 S101784 Hydraulic pressure sensor x x x x x x
2101 S101775 Circulating pump adapter x x x x x x
13 Spare parts
7600532 - v.11 - 13122018 85

DeDietrich C 330 Series Specifications

General

Brand	DeDietrich
Model	C 330 Series
Category	Boiler
Language	English
