Tab.43 Fan C 330 ECO
Markers Code no. Description 280 350 430 500 570 650
3001 S103275 Gas valve unit, 5 sectionsVR425 x
3001 S103276 Gas valve unit, 6 sectionsVR432 x
3001 S103277 Gas valve unit, 7/8/9 sectionsVR434 x x x
3002 S57770 Fan 5/6 sectionsG1G170 x x
3003 S103150 Fan 7/8/9/10 sectionsG3G250 x x x x
3004 S100347 Burner, 5 sections x
3004 S103077 Burner, 6 sections x
3004 S100329 Burner, 7 sections x
3004 S100330 Burner, 8 sections x
3004 S100331 Burner, 9 sections x
3004 S103078 Burner, 10 sections x
3005 S57791 Venturi assembly, 5 sections x
3005 S57792 Venturi assembly, 6 sections x
3005 S57793 Venturi assembly, 7/8/9 sections x x x
3005 S103079 Venturi assembly, 10 sections x
3006 S103151 Gas valve unit, 10 sections x
3007 S103073 Venturi - fan connecting piece, 7/8/9/10 sections x x x x
3007 S103072 Venturi - fan connecting piece, 5/6 sections x x
3009 S103071 Non-return valve x x x x x x
3010 S103074 Gas filter, 10 sectionsHFVR x x x x x x
3015 S103075 Air box, 5/6/7/8/9/10 sections x x x x x x
3016 S44483 Nut M8 (10 pieces) x x x x x x
3017 S103140 Gasket seal Ø 250 mm (2 pieces) x x x x x x
3018 S100570 Bolt M5 x 20 mm (10 pieces) x x x x x x
3020 S103042 Gas supply pipe, 5/6/7/8/9 sections, left x x x x x
3020 S103043 Gas supply pipe, 5/6/7/8/9 sections, left x x x x x
3023 S103279 Pressure measuring nipple, ⅛" x x x x x x
3025 S103280 Gasket seal 56 x 42 x 2 mm (5 pieces) x x x x x x
3026 S103047 Gas supply pipe, 5 + 6 sections, bottom right x x
3026 S103048 Gas supply pipe, 7/8/9 sections, bottom left x x x
3026 S103049 Gas supply pipe, 7/8/9 sections, bottom right x x x
3026 S103046 Gas supply pipe, 5 + 6 sections, bottom left x x
3027 S103281 Venturi gasket (2 pieces) x x x x x x
3031 S103266 Sealing plate for burner (2 pieces) x x x x x x
3033 S103283 Nut flange M12 (10 pieces) x x x x x x
3035 S103070 Mixing adaptor x x x x x x
3037 S103284 O-ring diameter 180 x 3.5 mm (5 pieces) x x x x x x
3039 S103285 O-ring diameter 111 x 4 mm (2 pieces) x x x x x x
3040 S46687 Nut flange M5 (10 pieces) x x x x x x
3041 S103286 Fan assembly plate x x x x x x
3042 S59650 Fan sealing plate x x x x x x
3044 S103288 Hose diameter 6 mm (1 metre) x x x x x x
3045 S103289 Elbow coupling M5 x 6 mm (5 pieces) x x x x x x
3046 S103076 Flexible hose, complete x x x x x x
3047 S103044 Gas supply pipe, 10 sections, left x
3047 S103045 Gas supply pipe, 10 sections, right x
3048 S103051 Gas supply pipe, 10 sections, bottom right x
3048 S103050 Gas supply pipe, 10 sections, bottom left x
3049 S59141 Bolt M5 x 18 mm (15 pieces) x x
3049 S15524 Bolt M8 x 16 mm (10 pieces) x x x x
13 Spare parts
86 7600532 - v.11 - 13122018
