Markers Code no. Description 280 350 430 500 570 650
3050 S100619 O-ring diameter 52.39 x 3.53 mm (5 pieces) x x x x x x
3051 S103290 Reduction nipple 2" x 1½" (2 pieces) x x x x x x
3052 S47170 Silicone hose Ø 4/8, 1000 mm x x x x x x
3053 S103287 O-ring Ø 130 x 3.5 mm (2 pieces) x x x x x x
3054 S103330 Flue damper gasket (5 pieces) x x x x x x
3055 S103356 Measuring nipple ⅛" (2 pieces) x x x x x x
3056 S103357 Adapter ⅛"- M5 (2 pieces) x x x x x x
3057 S100490 Insulation burner repair kit x x x x x x
3100 S103305 Gas leakage control VPS x x x x x
3100 S103306 Minimum gas pressure switch GPS x x x x x
3101 S101805 Minimum gas pressure switch GPS x
3101 S101724 Gas leakage control VPS x
3102 S103292 Gas filter, 10 sections x
3104 59212 Air inlet filter Ø 325 mm x x x x x x
Tab.44 Control panel C 330 ECO
Markers Code no. Description 280 350 430 500 570 650
4001 S43561 Fuse 2 AT (10 pieces) x x x x x x
4001 S103053 Control board PCU-06 x x x x x x
4003 S103235 Wiring harness 230V-1 x x x x x x
4004 S103236 Wiring harness 230V-2 x x x x x x
4005 S103232 On/Off switch x x x x x x
4007 S103067 Front panel x x x x x x
4008 S103068 Control panel back cover x x x x x x
4011 S100612 Plate screw 4.2 x 8 mm (20 pieces) x x x x x x
4016 S103065 Support DIEMATIC iSystem x x x x x x
4018 S103300 SU-01 PCB x x x x x x
4019 S103055 Extension PCB SCU-S05 (IniControl) x x x x x x
4019 S103056 Extension PCB (DIEMATIC iSystem) x x x x x x
4020 S103301 BUS Cable (IniControl) x x x x x x
4020 7600363 BUS Cable (DIEMATIC iSystem) x x x x x x
4022 S103063 Front panel x x x x x x
4023 S103240 Cable tree 24V-1 x x x x x x
4023 S103241 Wiring harness 24V-2 x x x x x x
4024 S103069 Snapper spacer (10 pieces) x x x x x x
4025 S100583 Spacer cap x x x x x x
4026 S14254 Plate screw 4.2 x 0.5 mm (DIEMATIC iSystem) x x x x x x
4027 S103315 Cable retainer (10 pieces) x x x x x x
4028 S103233 Cable RS232 x x x x x x
4029 S103299 Screw 2.9 x 19mm (10 pieces.) x x x x x x
4030 S103239 Bracket SCU (DIEMATIC iSystem) x x x x x x
4031 S101249 Display PCB (DIEMATIC iSystem) x x x x x x
4031
3000236
02
Display PCB (IniControl) x x x x x x
4032 S103061 Instrument panel lid x x x x x x
4033 S103234 Mounting plate for control panel x x x x x x
4034 S101681 Cable SCU -230 (DIEMATIC iSystem)V x x x x x x
4035 S103353 Ribbon cable (DIEMATIC iSystem) x x x x x x
4035 S103353 Ribbon cable (IniControl) x x x x x x
S103251 Ignition transformer x x x x x x
S103298 PSU-01 PCB x x x x x x
13 Spare parts
7600532 - v.11 - 13122018 87
