Tab.45 PartsC 630 ECO
Markers Code no. Description 560 700 860 1000 1140 1300
5001 S103128 Air supply manifold x x x x x x
5002 S103119 Flue gas outlet pipe Ø 250 mm/L = 890 mm x x x x x x
5003 S103318 Flue gas support x x x x x x
5004 S103313 Casing set, 5-7 sections x x x
5004 S103314 Casing set, 8-10 sections x x x
5005 7600368 Clamping ring + gasket seal Ø 250 mm x x x x x x
5006 7600369 Clamping ring + gasket seal Ø 350 mm x x x x x x
13 Spare parts
88 7600532 - v.11 - 13122018
